    In case anyone is curious, here are the conversions from liters to cubic inches for our current engines and cubic inches to liters for the 60s/70s engines. It's interesting to see that some of the 60s/70s engines are almost the identical size to their new counterparts (e.g., 198 c.i.= 3.2L, 225= 3.9L, 340= 5.6L and 383= 6.3L).

    Current Engines:

    3.5L= 214 cubic inches
    3.6= 220
    5.7= 348
    6.1= 372
    6.2= 378
    6.4= 392 (actually 390)

    60s/70s Engines:

    170 cubic inches= 2.8L
    198= 3.2L
    225= 3.9L
    318= 5.2L
    340= 5.6L
    383= 6.3L
    426= 7.0L
    440= 7.2L

  2. 70-426_10-SRT

    70-426_10-SRT Full Access Member

    Age:
    58
    Posts:
    352
    Likes Received:
    47
    Joined:
    Jun 25, 2018
    Location:
    PDX
    Fine, but don't you dare call my 74ci Harley Knuckle a 1200cc
    or my NEW 103ci Twin Cam a 1688cc


    :emotions122: :flipthebird: :nutkick:

  3. SRT-Tom

    SRT-Tom Full Access Member

    Posts:
    2,322
    Likes Received:
    182
    Joined:
    Oct 2, 2011
    Location:
    southern New Jersey

  4. 70-426_10-SRT

    70-426_10-SRT Full Access Member

    Age:
    58
    Posts:
    352
    Likes Received:
    47
    Joined:
    Jun 25, 2018
    Location:
    PDX
    :supergay:




    There were NO centimeters in 1947 :laughing1:

  5. Mats_B

    Mats_B Member

    Age:
    42
    Posts:
    11
    Likes Received:
    1
    Joined:
    Aug 11, 2017
    Location:
    Reftele
    The whole world used and use cm exempt the us even in 1940


    Skickat från min iPhone med Tapatalk

  6. 70-426_10-SRT

    70-426_10-SRT Full Access Member

    Age:
    58
    Posts:
    352
    Likes Received:
    47
    Joined:
    Jun 25, 2018
    Location:
    PDX
    And I have been fighting it, and Lead Free Solder, since they tried to introduce it since the '70's

    Of course I also had a problem with my Stealth when people would ask:
    "It that a GT3000?, No Damn it, it a Dodge, see the badging!"

  7. IntimidatorRT

    IntimidatorRT Moderator Staff Member

    Age:
    63
    Posts:
    581
    Likes Received:
    107
    Joined:
    Aug 8, 2017
    Location:
    Rosepine,LA.
    they have been saying that the 5.7 is 345CID. and from my conversion app. 345 Cu in is 5.653Liters

  8. SRT-Tom

    SRT-Tom Full Access Member

    Posts:
    2,322
    Likes Received:
    182
    Joined:
    Oct 2, 2011
    Location:
    southern New Jersey
    To get a precise figure, you have to convert liters to cubic inches. 5.653 liters is not the same as 5.7 liters. It is off by .047 liters. Dodge just chose to use the rounded up number to get 345 cubic inches. I guess that 345 sounds better than 348.

    See the following calculation:

    1 liter= 61.023744094732 cubic inches

    61.0237441 X 5.7= 347.8353 (348 rounded)


    https://www.conversion-metric.org/volume/litre-to-cubic_inch

    Last edited: Oct 29, 2018
  9. IntimidatorRT

    IntimidatorRT Moderator Staff Member

    Age:
    63
    Posts:
    581
    Likes Received:
    107
    Joined:
    Aug 8, 2017
    Location:
    Rosepine,LA.
    Not to argue but from my unit converter. [​IMG]


    Sent from my iPhone using Tapatalk

  10. 70-426_10-SRT

    70-426_10-SRT Full Access Member

    Age:
    58
    Posts:
    352
    Likes Received:
    47
    Joined:
    Jun 25, 2018
    Location:
    PDX
    O.K. actually, to a precise figure :boxing:

    It is just Bore^2 X Stroke X Number of Cylinders X .7854

    So a displacement of 345 cu in, (5,654 cc)
    has a bore of 3.917 in (99.49 mm)
    and a stroke of 3.578 in (90.88 mm).

    15.3429 x 3.578 x 8 x 0.7854 = 344.928 cubic inches
